60VC1600 46VC1200 28VC650 24VC1000 52VC1200 Airflex pneumatic clutch friction block brake lining used in oil rig industry

Overview

This products have been made by TRH3031 material, TRH3031 is a rigid molded product grey in colour utilising Kevlar fibers and a high percentage of brass chippings. TRH3031 offers excellent thermal resistance, compression and exhibits outstanding stability under heavy loads, at the same time maintaining a high resistance to wear.

Key Features

• ✅ Ultra-Durable Construction: molded by resin, glass fiber, and brass chipping, then show the stable quality and excellent performance

• ✅ High Wear Resistance: Withstands extreme mechanical and thermal loads

• ✅ Customizable Options: Available in sheets, segaments, ring and other shapes by mold

• ✅ Lead-Free, Asbestos-Free, Environmentally Safe

• ✅ Precision-Machinable for tailored Airflex pneumatic configurations or Oil rig platform.

Dimension：

Length x Width: 762mm x 762mm (30inches x 30 inches)

                           508mm x 508mm (20inches x 20 inches)

Thickness: 3.2mm—22mm ( 1/8 – 7/8 inch)

Oil rig brake pads measurements:

20VC600          46VC1200

52VC1200       11.5VC500

14VC500         16VC600

24VC650         28VC650

42VC650        14VC1000

16VC1000      18VC1000

24VC1000      28VC1000

32VC1000      38VC1200

42VC1200      51VC1600

60VC1600     35B7B/35CM500

40B7B/35CM550    48B7B/48CM650

26B7B/26CM475    30B7B/30CM500

Frictional Properties(SAE J661):

Normal       0.50

Hot             0.49

400°F         0.50

Recommended Operating Range：

Max. Pressure, psi                            300

Max. Rubbing Speed, ft/min            5000

Max. Intermittent Temperature        650°F (340°C)

Max. Continuous Temperature        600°F (315°C)

Application

TRH3031 brake pads are widely adopted in:

• Industrial brake and clutch systems

• Wind power transmission assemblies

• Oil drilling equipment (PTO systems)

• Electromagnetic brake engines

• Heavy-duty power transmission gearboxes

• Drilling and work over rig

• Airflex pneumatic clutch

FAQ

1.What is your terms of packing?
  Generally, we pack our brake pads/brake lining rolls in pallet with carton or box , also accept the customers' special requirements
2. What is your terms of payment?
   T/T 30% as deposit, and 70% before loading . We'll show you the photos of the products and packages before you pay the balance. Also, we accept flexible safe payment term, T/T, PAYPAL,ALIPAL etc.
3. What is your terms of delivery?
   Normally EXW, FOB, also CNF, CIF
4. How about your delivery time?
   About 30days - 50 days , Generally . If have stock, can send out within 1-3days.
5. Can you produce according to the samples?
   Yes, we can design and produce by your samples or technical drawings. We also can recommend the suitable material to meet your application.
6. What is your sample policy?
   We can supply the sample , but the customers have to pay the sample the courier cost. So before placing sample order, please ask us for confirmation in advance.
7: How do you make our business long-term and good relationship?
    1). We keep good quality and competitive price to ensure our customers benefit ;
    2). We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
9: What's your best convenient contact way:
    We check and reply email everyday, 24 hours phone service, use whatsapp/wechat everyday.

Let’s Build the Future of Friction Together

Looking for a long-lifespan, non-asbestos, and high-precision gear disc plate supplier?
Talfri offers the performance, safety, and reliability that global industries demand, can provide suitable choice.

Contact us today to request samples, technical data sheets, or custom solutions tailored to your equipment needs.
