TRH3031
TALFRI
650F(340℃)
600F(315℃)
| Quantity: | |
|---|---|
Overview
TRH3031 is a rigid molded product grey in colour utilising Kevlar fibers and a high percentage of brass chippings. TRH3031 offers excellent thermal resistance, compression and exhibits outstanding stability under heavy loads, at the same time maintaining a high resistance to wear. TRH3031 is manufactured in sheets, segments, rings and many special shapes by either machining or moulding.
Key Features
✅ Ultra-Durable Construction: Molded by Kevlar fibers, and brass chipping, resin and other fibers
✅ High Wear & Compression Resistance: excellent thermal stability and impact strength, while maintaining a low wear rate
✅ Customizable brake pads : Available in 65.3x10mm and 64.8x10mm or customized other specifications
✅ Lead-Free, Asbestos-Free, Environmentally Safe
✅ Precision-Machinable for tailored industrial DBS DBK brake clutch brake pads
Dimension：
DBS DBK Brake pads: 65.3x46.2x14.6mm&65.3x10mm&64.8x10mm
Flat sheet
Length x Width: 762mm x 762mm (30inches x 30 inches)
508mm x 508mm (20inches x 20 inches)
Thickness: 3.2mm—22mm ( 1/8 – 7/8 inch)
Can be made other sizes or shape by molded
Frictional Properties(SAE J661):
Normal 0.50
Hot 0.49
400°F 0.50
Recommended Operating Range：
Max. Pressure, psi 300
Max. Rubbing Speed, ft/min 5000
Max. Intermittent Temperature 650°F (340°C)
Max. Continuous Temperature 600°F (315°C)
TRH3031 brake pads are widely adopted in:
Industrial brake and clutch DBS DBK systems
Wind power transmission assemblies
Papermaking and printing equipment
Electromagnetic brake engines
Heavy-duty power transmission brake rings
Transport&Payment
Many different formulas of materials to meet various applications
can be customized according to requirements, and small batches can also be made
1.Q: How can I get the samples?
A: If you wish to obtain samples for testing, you are required to cover the transportation costs and the sample fees. However, upon placing an order, these sample costs can be reimbursed. Alternatively, you might be eligible for a complimentary Blank Sample.
2. Q: How to order?
A: Kindly send us your purchase order via Email or social media like Wechat/Whatapp, or request a Proforma invoice from us. For a seamless order process, please provide the following information.
1) Product information - Quantity, Specification (Size, Material, Technology, and Applicaitons, etc.)
2) Desired delivery timeline
3) Shipping information - Company name, Street address, Phone & Fax number, Destination sea port.
4) Contact details of any designated forwarder in China.
3. When can you get the price?
Typically, we provide quotes within 24 hours of receiving your inquiry. If urgency is a factor, please reach out via phone or emphasize it in your email for prioritized attention. Detailed inquiries enable us to offer more precise pricing.
4. How can you get a sample to check our quality?
Following price confirmation, samples are available upon request to ascertain our quality standards.
Should you require a blank sample to evaluate design or quality, we offer it free of charge, with only the express freight to be covered by you.
5. Can we do the design or drawing for you?
Yes, certainly. Our expert team, rich in experience with brake pads or friction block and manufacturing, is at your service. Share your ideas or applications with us, and we'll recommend the suitable material and make the drawing to you for approval.
