249022A3 480 580
TALFRI
| Quantity: | |
|---|---|
Overview
The clutch brake pads of 249022A3 have been made by the material TRH3020.
TRH3020 is a rigid molded Non Asbestos Brake Sheet of medium and high frictional coefficient. The flat sheet exhibits excellent resistance to heat and compression and outstanding stability in applications.
Dimension
Length x Width: 762mm x 762mm (30inches x 30 inches) or 508mm x 508mm (20inches x 20inches)
Thickness：3.2mm—25.4mm ( 1/8 – 1inch)
TRH3020 sheet can be processed into segments or rings and other shapes by tooling or machining.
Frictional Properties
Normal 0.50
Hot 0.48
400°F 0.50
Recommended Operating Range
Max. Pressure, psi 280
Max. Rubbing Speed, ft/min 5000
Max. Intermittent Temperature 650°F (340°C)
Max. Continuous Temperature 600°F (315°C)
TRH3020 friction materials are widely adopted in:
Industrial brake and clutch systems
Wind power transmission assemblies
Oil drilling equipment (PTO systems)
Electromagnetic brake engines
Heavy-duty power transmission equipment
Agricultural machinery
Trading Capacity:
International Commercial Terms (Incoterms): FOB, EXW, CNF, CIF, offering flexible options to suit your trading needs
Terms of Payment: LC, T/T, ALIPAY, PAYAPL, tailored for secure and convenient transactions
Average Lead Time: Peak Season Lead Time: two months, Off Season Lead Time: within 20 workdays, ensuring timely delivery throughout the year
Export Year: 1999-03-01, marking our expansion into global markets
Export Percentage: 70%~80%, a testament to our significant presence in international trade
Main Markets: North America, South America, Eastern Europe, Southeast Asia, Oceania, Mid East, Eastern Asia, Western Europe, showcasing our widespread global reach
Looking for a long-lifespan, non-asbestos, and high-precision friction materials supplier?
Talfri Brakes offers the performance, safety, and reliability that meet the global industries demand, it involves industries such as marine deck machinery, petroleum, offshore engineering, industry, mining, coal, etc, there are many types of friction plates, and they can also be customized for small quantities.
Contact us today to request samples, technical data sheets, or custom solutions tailored to your equipment needs.
