TL3000
TALFRI
0.45-0.55
TL3000 is a high-performance, non-asbestos laminated friction sheet designed for heavy-duty industrial applications. Engineered with Kevlar®, glass fiber, synthetic yarns, and embedded brass wire, TL3000 combines exceptional hardness, tensile strength, and thermal stability. This material is ideal for machining into gear tooth facing discs used in brake and clutch assemblies across sectors such as oil drilling, wind power, and power transmission.
✅ Ultra-Durable Construction: Woven from Kevlar®, glass fiber, and brass wire, then resin-impregnated and pressed for maximum rigidity
✅ High Wear & Compression Resistance: Withstands extreme mechanical and thermal loads
✅ Customizable Gear Options: Available in 60-teeth (11") and 72-teeth (14") specifications
✅ Lead-Free, Asbestos-Free, Environmentally Safe
✅ Precision-Machinable for tailored industrial clutch/brake configurations
Size:
60 Teeth 11" 300.5x220x12mm
72 Teeth 14" 370x255x12mm
Frictional Properties:
Normal 0.47
Hot 0.45
Static @200°F 0.47
Static @400°F 0.48
Mechanical properties:
Tensile Strength 4300psi
Compression Strength 20300psi
Direct Shear Strength 4700psi
Recommended Operating Range：
Max. Pressure, psi 800
Max. Rubbing Speed, ft/min 5000
Max. Intermittent Temperature 600°F (315°C)
Max. Continuous Temperature 550°F (287°C)
TL3000 gear tooth disc plates are widely adopted in:
Industrial brake and clutch systems
Wind power transmission assemblies
Oil drilling equipment (PTO systems)
Electromagnetic brake engines
Heavy-duty power transmission gearboxes
Guiyang Talfri Brakes Co., Ltd. was established on March 1, 1999. It is a private high-tech enterprise in Guiyang City, Guizhou Province. Its production base is located in the Chemical New Materials Industrial Park, Xinghong Village, Zazuo Town, Xiwen County, Guiyang City, covering an area of 23 mu, with nearly 8,000 square meters of factory buildings and office buildings. The company currently has 85 employees, among whom 26 have a college degree or above, accounting for 30.58% of the total number of staff. The company mainly engages in the research and development, production and sales of industrial friction materials. The friction materials it researches and produces are a series of products such as "brake linings (blocks) and clutch face plates for industrial (agricultural) machinery". Currently, the products include five major categories: braided type, laminated type, pressed type, extruded type and carbon-ceramic composite materials, with a total of more than ten varieties. It is the enterprise with the most complete range of products and the best product quality among similar domestic enterprises (mainly referring to industrial applications), and it is a leader among similar domestic enterprises.
Looking for a long-lifespan, non-asbestos, and high-precision gear disc plate supplier?
Talfri offers the performance, safety, and reliability friction materials that meet global industries demand.
Contact us today to request samples, technical data sheets, or custom solutions tailored to your equipment needs.
