Overview:
TRH3051 is a medium-low coefficient friction material in gray color. This friction material has excellent thermal stability and low wear rate. TRH3051 can be produced into rings or other special-shaped friction blocks by tooling or machining.
Applications：
TRH3051 is mainly used in clutches under light and medium loads or other applications requiring torque limitation. This material is only suitable for dry friction.
Dimension：
508mm x 508mm (20inches x 20 inches)
Thickness: 3.2mm—25.4mm ( 1/8 – 7/8 inch)
Frictional Properties(SAE J661):
Normal 0.25
Hot 0.20
400°F 0.22
Recommended Operating Range：
Max. Pressure, psi 250
Max. Rubbing Speed, ft/min 5000
Max. Intermittent Temperature 650°F (340°C)
Max. Continuous Temperature 600°F (315°C)
