TL3000
TALFRI
0.45-0.55
650F(340℃)
600F(315℃)
| Quantity: | |
|---|---|
Overview
TL3000 is a Non Asbestos Woven Laminated Sheet with exceedingly high hardness and strength. The material is woven from Kevlar, glass fiber and other synthetic fabric yarns containing brass wire. After being impregnated with special resin and pressed into rigid flat sheet, the material shows outstandingly good resistance to wear and compression and excellent stability.TL3000 can be processed into gear teeth facing due to its high hardness and strength.
✅ Ultra-Durable Construction: Woven from Kevlar®, glass fiber, and brass wire, then resin-impregnated and pressed for maximum rigidity
✅ High Wear & Compression Resistance: Withstands extreme mechanical and thermal loads
✅ Customizable Sheet Options: Available in 1000mmx1000mm specifications
✅ Lead-Free, Asbestos-Free, Environmentally Safe
✅ Precision-Machinable for tailored industrial clutch/brake configurations, can be made by molded
Application
TL3000 is a heavy duty material extensively used in oil drilling and wind power industry. It can be installed in industrial brake and clutch system,PTO，power transmission system and electric magnetic brake engine.
Size
Length x Width: 1000mm x 1000mm (40 inches x 40 inches)
Thickness：3.2mm—60mm ( 1/8inch – 2.36 inch)
Frictional Properties
Normal 0.47
Hot 0.45
Static @200°F 0.47
Static @400°F 0.48
Mechanical properties:
Tensile Strength 4300psi
Compression Strength 20300psi
Direct Shear Strength 4700psi
Recommended Operating Range：
Max. Pressure, psi 800
Max. Rubbing Speed, ft/min 5000
Max. Intermittent Temperature 600°F (315°C)
Max. Continuous Temperature 550°F (287°C)
Trading Capacity:
International Commercial Terms (Incoterms): FOB, EXW, CFR, CIF, offering flexible options to suit your trading needs.
Terms of Payment: LC, T/T, ALIPAY, PAYPAL etc.
Average Lead Time: Peak Season Lead Time: two month, Off Season Lead Time: within 20 workdays, ensuring timely delivery throughout the year, If normal size, most of them have the stock.
Number of Foreign Trading Staff: 4~10 People, a dedicated team ensuring smooth international operations
Export Year: 1999-03-01, marking our expansion into global markets
Export Percentage: 70%~80%, a testament to our significant presence in international trade
Main Markets: North America, South America, Western Europe,Eastern Europe, Southeast Asia, Oceania, Mid East, Eastern Asia, showcasing our widespread global reach
Nearest Port: Shenzhen Port, strategically located for efficient logistics
Looking for a long-lifespan, non-asbestos, and high-precision friciton sheet supplier?
TL3000 by Talfri offers the performance, safety, and reliability that meet global industries demand.
Contact us today to request samples, technical data sheets, or custom solutions tailored to your equipment needs
