High Performance High Durability Gear Tooth Clutch Disc (external Teeth) for Industrial Clutch Brakes Power Transmission system

Overview:

TL3000 is a Non Asbestos Woven Laminated Sheet with exceedingly high hardness and strength. The material is woven from Kevlar, glass fiber and other synthetic fabric yarns containing brass wire. After being impregnated with special resin and pressed into rigid flat sheet, the material shows outstandingly good resistance to wear and compression and excellent stability.TL3000 can be processed into gear teeth facing due to its high hardness and strength.

Key Features

• ✅ Ultra-Durable Construction: Woven from Kevlar, glass fiber, and brass wire, then resin-impregnated and pressed for maximum rigidity

• ✅ High Wear & Compression Resistance: Withstands extreme mechanical and thermal loads

• ✅ Customizable Gear Options: Available in 6"(42teeth)-8"(51teeth)-10"(63teeth)-11"(72teeth)-14"(59teeth)-18"(75teeth) -21"(87teeth) specifications, also can be customized follow the drawing

• ✅ High coefficient: 0.45-0.55

• ✅ Thermal expansion and thermal growth： No more than 2.5%

• ✅Low wear resistance: No more than 0.01 In3/Hp-hr

• ✅High strength: More than 52MPA


• ✅ Precision-Machinable for tailored industrial clutch/brake configurations

Size:

6"    42teeth

7"    47teeth

10"  63teeth

11"  72teeth

14"  59teeth

18"  75teeth

21"  87teeth

Also can follow the drawing or sample to make it.

Frictional Properties:

Normal                         0.40-0.55

Hot                               0.40-0.52

400°F                            0.40-0.50

Mechanical properties:

Tensile Strength                            ≥50MPa

Circumferential shear strength     ≥80MPa

Rockwell hardness                        85-115HRM

Recommended Operating Range：

Max. Pressure, psi                                800

Max. Rubbing Speed, ft/min               5000

Max. Intermittent Temperature           600°F (315°C)

Max. Continuous Temperature           550°F (287°C)

Application Scenarios

TL3000 gear tooth disc plates are widely adopted in:

• Industrial brake and clutch systems

• Wind power transmission assemblies

• Oil drilling equipment (PTO systems)

• Electromagnetic brake engines

• Heavy-duty power transmission gearboxes

• Construction machinery and equipment

• Agricultural machinery

Why Choose Talfri?

About Guiyang Talfri Brakes Co., Ltd.

With over 25 years of experience, Guiyang Talfri Brakes Co., Ltd. is the first and only Chinese manufacturer of non-asbestos laminated friction materials. We are the leading manufacturer of non asbestos friction material in China. With high quality, top class service and prompt delivery, more than 80% of our products have been exported to worldwide market and win high comments from our customers and end-users. Our quality is deserved your trust.

Certifications & Compliance

• ISO 9001:2015 & IATF 16949:2016 certified

• DNV & CCS quality type approved

• Fully compliant with SAE-J661 test standard & asbestos-free standards

• Traceable production with inspection reports, CoC, and performance tests available

R&D Commitment

• Over 6% of annual revenue invested in R&D

• In-house lab with full friction material testing capabilities

• Holder of multiple patents for high-performance composite formulations





Partner

FAQ

1. How many items of friction material brake pads?
   More than 1000 models.

2. Could you produce according to samples?
   Yes, we can design and produce according to your samples or technical drawings.

3. Do you have any certificates?
   Yes, IATF16949, ISO9001, DNV, CCS, etc.

4. How long is the delivery time?
   45-55 days after receiving the deposit and all details were confirmed for the new style, 20days for the reorder.

5. Could you please provide me the catalog of Talfri brake?
   Yes, please share your email ID or contact us, the catalog will be sent to you soon.
