TRH3098
TALFRI
0.40-0.42
| Quantity: | |
|---|---|
Overview
TRH3098 is a non-metallic friction sheet with medium friction coefficient. The material contains a certain component of aramid pulp, polyacrylonitrile fiber and mineral fiber, which has excellent thermal stability and impact strength, maintaining a low wear rate
Application:
TRH3098 is used in industrial and agricultural motor brake application widely, especially is suitable for special-shaped brakes.
Flat Sheet Size:
762mmx762mm
508mmx508mm
Produced by tooling or machining of drawings.
Frictional Properties:
Normal 0.42
Hot 0.40
400°F 0.40
Recommended Operating Range：
Max. Pressure, psi 280
Max. Rubbing Speed, ft/min 5000
Max. Intermittent Temperature 650°F (340°C)
Max. Continuous Temperature 600°F (315°C)
